Auto-Generate OpenAPI and Swagger UI in Go with Rivaas

Keeping an OpenAPI file up to date by hand is slow and easy to get wrong. Your code changes, but the spec does not, and clients stop trusting the docs. Rivaas helps by building the OpenAPI document when your app runs. You describe each route next to the handler, and your Go types become JSON Schema in the spec. This tutorial shows a small working API and where to open Swagger UI.

OpenAPI is the standard format for describing HTTP APIs. Swagger UI is the page that lets you try requests against that description.

How Rivaas fits in

#

You turn on OpenAPI on the app with app.WithOpenAPI(...). For each route, you pass app.WithDoc(...) and options from rivaas.dev/openapi, such as openapi.WithSummary, openapi.WithRequest, and openapi.WithResponse.

By default the spec follows OpenAPI 3.0.x, which most tools understand well. If you need OpenAPI 3.1.x (closer to JSON Schema 2020-12), add openapi.WithVersion(openapi.V31x) inside app.WithOpenAPI.

Tools like swaggo/swag generate a spec from comments and need a build step. Here your types and WithDoc options stay close to the routes, and the spec is generated at runtime—no swag init for the spec itself.

Example types

#

These structs are normal Go models. They are also what Rivaas uses to fill in request and response schemas in the spec when you reference them in WithDoc:

type CreateOrderRequest struct {
	CustomerID string      `json:"customer_id" validate:"required"`
	Items      []OrderItem `json:"items"       validate:"required,min=1"`
	Notes      string      `json:"notes,omitempty"`
}

type OrderItem struct {
	ProductID string `json:"product_id" validate:"required"`
	Quantity  int    `json:"quantity"    validate:"required,min=1"`
}

type CreateOrderResponse struct {
	OrderID   string    `json:"order_id"`
	Status    string    `json:"status"`
	CreatedAt time.Time `json:"created_at"`
}

Rivaas maps json tags to property names. It uses validation tags like validate:"required" to mark required fields where supported. Fields with omitempty are treated as optional in the schema. For edge cases and full rules, see the schema generation guide.

Step 1: Create the project

#

mkdir orders-api && cd orders-api
go mod init example.com/orders
go get rivaas.dev/app
go get rivaas.dev/openapi

Step 2: Add a full main.go

#

The app below enables OpenAPI and Swagger UI at /docs. It registers POST /orders with a documented request and response. MustBind reads and validates the JSON body; if something is wrong, Rivaas sends an error response and the handler returns early.

package main

import (
	"context"
	"log"
	"net/http"
	"time"

	"rivaas.dev/app"
	"rivaas.dev/openapi"
)

type CreateOrderRequest struct {
	CustomerID string      `json:"customer_id" validate:"required"`
	Items      []OrderItem `json:"items"       validate:"required,min=1"`
	Notes      string      `json:"notes,omitempty"`
}

type OrderItem struct {
	ProductID string `json:"product_id" validate:"required"`
	Quantity  int    `json:"quantity"    validate:"required,min=1"`
}

type CreateOrderResponse struct {
	OrderID   string    `json:"order_id"`
	Status    string    `json:"status"`
	CreatedAt time.Time `json:"created_at"`
}

func main() {
	a, err := app.New(
		app.WithServiceName("orders-api"),
		app.WithServiceVersion("1.0.0"),
		app.WithOpenAPI(
			openapi.WithDescription("Small example API with generated OpenAPI and Swagger UI."),
			openapi.WithServer("http://localhost:8080", "Local"),
			openapi.WithSwaggerUI("/docs"),
		),
	)
	if err != nil {
		log.Fatal(err)
	}

	a.POST("/orders", createOrder,
		app.WithDoc(
			openapi.WithSummary("Create order"),
			openapi.WithRequest(CreateOrderRequest{}),
			openapi.WithResponse(http.StatusCreated, CreateOrderResponse{}),
			openapi.WithTags("orders"),
		),
	)

	if err := a.Start(context.Background()); err != nil {
		log.Fatal(err)
	}
}

func createOrder(c *app.Context) {
	var req CreateOrderRequest
	if !c.MustBind(&req) {
		return
	}
	resp := CreateOrderResponse{
		OrderID:   "ord_001",
		Status:    "pending",
		CreatedAt: time.Now().UTC(),
	}
	_ = c.JSON(http.StatusCreated, resp)
}

Step 3: Run the server and open Swagger UI

#

go run .

• GET /openapi.json — JSON document for your API. You can change the path with openapi.WithSpecPath if needed.
• GET /docs — Swagger UI (because of openapi.WithSwaggerUI("/docs")).

Open http://localhost:8080/docs in a browser to explore and try the operation.

Step 4: Optional API metadata and OpenAPI 3.1

#

app.WithServiceName and app.WithServiceVersion feed into the spec’s title and version. You can also set them directly:

app.WithOpenAPI(
	openapi.WithTitle("Order Service API", "1.0.0"),
	openapi.WithDescription("Manage customer orders."),
	openapi.WithVersion(openapi.V31x), // use 3.1.x; omit for default 3.0.x
	openapi.WithSwaggerUI("/docs"),
)

For auth in the spec, common helpers include openapi.WithBearerAuth and openapi.WithAPIKeyAuth. See OpenAPI configuration for the full list.

Compare approaches

#

More detail on operations and schemas

#

Per-route options (summaries, examples, security, multiple responses) are listed in the operation options reference and the operations guide. Validation tags such as validate:"min=1,max=100" can appear as JSON Schema limits where the generator supports them. Optional spec self-check (meta-validation) is off by default for speed; see validation if you want to turn it on in development or CI.

Next steps

#

• OpenAPI guides — install, configure, security, diagnostics
• App package: OpenAPI — how WithOpenAPI and WithDoc work together
• OpenAPI package reference
• Swagger UI options

Run your service, open /docs, and use the live spec as the single place your team and clients read for this API.
